HDPE 5510 (HBM5510) – Large Blow Moulding Grade
HDPE 5510 (HBM5510) is a hexene-copolymer HDPE for large blow-moulded parts such as jerry cans and open-top drums, with high stiffness and good ESCR.
- HLMI 10 g/10 min 190 °C / 21.6 kg
- Density 0.955 g/cm³
- ESCR 90 h
- Reply within one business day on WhatsApp or email
- Sea to Karachi or Port Qasim, road via Taftan
- Producer, lot and packing confirmed in every offer
HDPE 5510 (HBM5510) is a hexene-copolymer HDPE for large blow-moulded parts such as jerry cans and open-top drums, with high stiffness and good ESCR.
HDPE 5510 Technical Data
| Property | Test Method | Unit | Typical Value |
|---|---|---|---|
| Physical | |||
| Melt Flow Rate (190 °C / 21.6 kg) | ISO 1133 | g/10 min | 10 |
| Density | ISO 1183 | g/cm³ | 0.955 |
| Mechanical | |||
| Tensile Modulus | ISO 527 | MPa | 1100 |
| Tensile Stress at Yield | ISO 527 | MPa | 27 |
| Tensile Strain at Yield | ISO 527 | % | 8 |
| Notched Tensile Impact (-30 °C) | ISO 8256 | kJ/m² | 135 |
| Ball Indentation Hardness | ISO 2039-1 | MPa | 49 |
| Other | |||
| ESCR | Producer method | h | 90 |
Typical values from the producer’s published data sheet. Values marked min or max are specification limits. Ask for the certificate of analysis of the lot on offer.
Key Features
- High stiffness
- Good ESCR
- High parison melt strength
- Hexene comonomer
Iranian producers of HDPE 5510
HDPE 5510 is produced in Iran by Arya Sasol Polymer (HBM5510). Rabin Polymer is an independent supplier and exporter, not an official agent of these producers – the producer, lot and packing of each shipment are confirmed in the offer.
Applications
- Jerry cans
- Open-top drums
- Large blow-moulded containers
Processing Guide
- Process: Blow moulding
- Barrel temperature: 180 – 220 °C
- Melt temperature: 200 – 235 °C
HDPE 5510 for buyers in Pakistan
In Karachi rate lists this grade trades under HDPE Blow Moulding (prime, virgin plastic dana). Ask for the rate CFR Karachi or for road delivery via Taftan.
- Sea: 20′ / 40′ containers from Bandar Abbas to Karachi or Port Qasim
- Road: trucks via Taftan to Pakistan, and via Turkmenistan to Central Asia
- Packing: 25 kg bags, palletised; jumbo bags on request
- Documents: commercial invoice, packing list, certificate of origin and the producer datasheet
HDPE 5510 FAQ
What is HDPE 5510 used for?
Jerry cans, Open-top drums and Large blow-moulded containers.
Who produces HDPE 5510 in Iran?
Arya Sasol Polymer. We confirm the producer for each lot.
How do I get today’s HDPE 5510 rate?
Send the grade, quantity and destination on WhatsApp or use the enquiry form. We reply within one business day.
We reply within one business day.
Request a Quote
Tell us the grade, quantity and destination – we reply with price, availability and delivery terms within one business day. Samples and full export documents are available on request.
Talk to Sales
- WhatsApp: +98 912 640 4020
- Email: sales@rabinpolymer.com
- WhatsApp: +98 912 859 5824
- Tel: +98 21 25903
- Tel: +98 21 2611 6515
- Office: Coral Tower, 7th Kouhestan St, Pasdaran, Tehran
- Factory: Eyvanaki Industrial Zone, Semnan province
- Dubai office: Rasis Business Centre, Al Barsha 1, Dubai, UAE
- Tel / WhatsApp (UAE): +971 58 687 5544
Road, sea or rail – shipping mode agreed per order · Pre-shipment inspection on request · Full export documents
